Hopper Dryer Stands

Category:

Product Description

Yann bang hopper dryer stands are available for all model hopper dryers and are on wheels to enable the hopper dryer mounted on the stand to be moved with ease.

Reviews

There are no reviews yet.

Be the first to review “Hopper Dryer Stands”

Your email address will not be published. Required fields are marked *

Related products

  • Drying Equipment

    Hopper Dryers

    Yann Bang Hopper Dryers are available in sizes from 12kg to 1200kg capacity. The hoppers are all stainless steel and have shut off valves, dump chutes and sight glasses. They are all designed to take any Yann Bang hopper loader without any drilling or fitting required. MADE IN TAIWAN.

    View specs

    Model Capacity Height Width Depth Base Diameter Heater
    HD12 28.12 796 619 335 1202 2kw
    HD25 52.60 1005 696 418 1602 3kw
    HD50 92.21 1145 797 492 1602 3.85kw
    HD100 202.34 1415 1021 432 2252 7kw
    HD200 372.66 1610 1149 775 2252 11kw
    HD400 665.81 2006 1149 945 3202 20kw
    HD600 804.84 2251 1450 945 3202 20kw

  • Dehumidifier Dryers

    Yann Bang Dehumidifier Dryers use a rotating desiccant multi cannister system that takes all spikes out of the airflow giving dry air better than -40°C and generally around -50°C. They come in all sizes from 100m³/Hr to 1750m³/Hr and are able to dry for example 1000kg of PET per hour.  MADE IN TAIWAN

    View Specs

    DHC60 DHC80 DHC100 DHC200 DHC400 DHC600 DHC700 DHC800
    Air flow m3 hr 50 80 100 180 300 450 580 730
    Heater KW 3 3.8 3.8 7.8 9 9 13 18
    Blower KW .5 1 1 2.5 3.5 5 7.5 10
    Dimensions LxWxH  69x60x140  69x60x140  69x60x140  69x60x160  87x87x198  87x87x198 125x125x236 125x125x236

  • Dryer Dust Filters

    Yann Bang Dryer Dust Filters are available for all model hopper dryers and remove all dust from the air leaving the hopper dryer operating area dust free.

  • Dryer Magnet Bases

    Yann Bang Dryer Magnet Bases are available for all model hopper dryers and allow magnets to be installed at the base of the hopper dryers in a sight glass where the state of the magnet can be viewed and removed for cleaning if necessary without upsetting the drying process.
