GWK die temperature controllers

Product Enquiry

Product Description

GWK are one of the worlds most famous Die temperature Controller manufacturers and are the preferred supplier of many of Europe’s most famous processing machinery manufacturers. They come in sizes from 3kW to 300 kW of heating and a temperature range of up to 350°C.

GWK models are very sophisticated yet very user friendly, the controllers can be interfaced using any of the current interfaces with the processing machines controller.

Typical units used in the plastics industry are:
GWK CS90 9kw heating to 90°C.
GWK CS140 9kW heating to 140°C.
All models come with ‘leakstop’

View specs

Model CS90 CS140
Medium Water Water
Temperature max (C) 95 140
Pump capacity max (l/min/bar) 60/3.8 60/6
Heating capacity (kw) 9 9
Cooling Indirect Indirect
Cooling capacity (kw/kcal/hr) 23/20,000 40/34,400
Weight (kg) 44 50
Robust stainless steel housing with painted side panels Yes Yes
Automatic filling and top up device Yes Yes
Strainer in cooling water inlet Yes Yes
Durable rubber coated castors Yes Yes
All contact parts made of non-corrosive materials Yes Yes
Continuous heater control Yes Yes
Acoustic alarm Yes Yes
Additional manual filling operation for treated water Yes Yes
Leak stop operation Yes Yes
Mould draining facility Yes Yes
Magnetically couples pump
Integrated to up pump
Mould circuit supply and return connections G1/2″ G1/2″
Cooling water supply and return connections G1/4″ G1/4″
Dimensions of housing (LxWxH) 680x250x595 680x250x595
